Competitive price engine KTA19-G4 500Kva 400KW diesel generator

FOB Reference Price:Get Latest Price
$11,000.00 - $20,000.00 / Sets | 1 Set/Sets (Min. Order)
Rated Power:
400KW 500Kva
Output Type:
AC Three Phase
Lead Time:
Quantity(Sets) 1 - 5 6 - 10 >10
Est. Time(days) 15 20 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
weichai
Model Number:
WPG550
Rated Voltage:
400/230V
Rated Current:
Depend
Speed:
1500/1800rpm
Frequency:
50/60HZ
Engine:
with weichai cumminss deutz perkins etc
Type:
Silent(super Silent)or Open
Options:
ATS
Product Name:
400kw diesel generator
Alternator:
Weichai/Marathon/Staford
Controller:
Deepsea/smartgen/etc...
Excitation:
Brushless Excitation
Color:
Customers' Requirement
Engine Model:
KTA19
Warranty:
12 Months/1000 Hours
Supply Ability
Supply Ability:
1000 Set/Sets per Month
Packaging & Delivery
Packaging Details
good original packing plywood for KTA19-G4 500Kva 400KW diesel generator
Port
Tianjin /Qingdao
Lead Time :
Quantity(Sets) 1 - 5 6 - 10 >10
Est. Time(days) 15 20 To be negotiated
Video Description
Product Description
Sheetdata
Technical parameters of diesel generator sets:
Technical data
Genset Model
GF-550
 Prime Power
400KW/500KVA
Rated Voltage
400/230V
Frequency
50/60Hz
Power Factor
0.8(lagging)
The regulating rate of steady voltage
≤±0.5%
The regulating rate of instantaneous voltage
≤-15%/ +20%
The time of steady voltage
≤1.5sec
The waving rate of voltage
≤1.0%
The regulating rate of steady frequency
≤3%
The regulating rate of instantaneous frequency
≤±10%
The time of steady frequency
3sec
Dimension (L×W×H) (mm)
3400*1260*2050
Genset weight (kg)
4300
Diesel Engine
Brand
With cummins
Model
KTA19-G4
Number of Cylinders
6
Rotating Speed
1500/1800RPM
Cycle
Four stroke
Type
waste gas turbine boost,direct spurting type
Bore×Stroke(mm)
159*159
Displacement(L)
19
Compression ratio
13.9:1
Speed Governor
Electrical
Cooling System
Water-cooled
Speed Stability (%)
≤5%
Fuel Consumption at 100% Load
203g/kw.h
Starting Method
DC24V Electrical starting
Alternator
Brand
Stamford type
Model
HCI544D
Number of Phase
3
Connecting Type
Three Phase and Four Lines
Number of Bearing
1
Grading Protection
IP22
Altitude
≤1000m
Exciter Type
Brushless (AVR automatic voltage regulating)
Insulation Class
H degree
The components of the genset
(1) Cummins Diesel Engine;        (2)Shanghai Stamford Alternator;     (3) Control Panel
The control panel is Quadruplication protection control panel, with the display of frequency table/water temperature/schedule/battery voltmeter. The genset with low oil pressure, high water temperature, over speed emergency, stop and other pre-protection.

Genset with cummins engine+Stamford Alternator(50Hz,1500Rpm)

Genset

Model
With Cummins engine model
Alternator Model
Gensets Power
Standby Power
Gensets Power
Rated Power
Engine Power

engine
Stamford
Kva
KW
Kva
KW
KW/Kva
GF-22C
4B3.9-G2
PI144D
22
18
20
16
24kw/30kva
GF-28C
4B3.9-G2
PI144E
28
22
25
20
24kw/30kva
GF-30C
4B3.9-G2
PI144F
30
24
27
22
24kw/30kva
GF-33C
4BT3.9-G2
PI144G
33
26
30
24
36kw/40kva
GF-39C
4BT3.9-G2
PI144H
39
31
35
28
36kw/40kva
GF-44C
4BT3.9-G2
PI144J
44
35
40
32
36kw/40kva
GF-47C
4BTA3.9-G2
PI144K
47
37
43
34
50kw/62.5kva
GF-55C
4BTA3.9-G2
UCI224D
55
44
50
40
50kw/62.5kva
GF-62C
4BTA3.9-G2
UCI224E
62
50
56
45
50kw/62.5kva
GF-80C
6BT5.9-G2
UCI224F
80
64
73
58
87kw/109kva
GF-94C
6BT5.9-G2
UCI224G
94
75
85
68
87kw/109kva
GF-103C
6BT5.9-G2
UCI274C
103
83
94
75
87kw/109kva
GF-110C
6BTA5.9-G2
UCI274C
110
88
100
80
110kw/135kva
GF-124C
6BTA5.9-G2
UCI274D
124
99
113
90
110kw/135kva
GF-138C
6BTAA5.9-G2
UCI274E
138
110
125
100
120kw/150kva
GF-154C
6CTA8.3-G2
UCI274E
154
123
140
112
163kw/204kva
GF-176C
6CTA8.3-G2
UCI274F
176
141
160
128
163kw/204kva
GF-200C
6CTA8.3-G2
UCI274G
200
160
182
146
163kw/204kva
GF-220C
6CTAA8.3-G2
UCI274H
220
176
200
160
200kw/250kva
GF-253C
6LTAA8.9-G2
UCDI274J
253
202
230
184
235kw/294kva
GF-275C
6LTAA8.9-G2
UCDI274K
275
220
250
200
220kw/240kva
GF-275C1
NT855-GA
UCDI274K
275
220
250
200
231kw/289kva
GF-313C
NTA855-G1A
HCI444D
313
250
275
220
261kw/326kva
GF-330C
NTA855-G1B
HCI444D
330
264
300
240
284kw/355kva
GF-344C
NTA855-G1B
HCI444ES
344
275
313
250
284kw/355kva
GF-378C
NTA855-G2A
HCI444E
378
303
344
275
313kw/391kva
GF-385C
NTA855-G4
HCI444E
385
308
350
280
317kw/391kva
GF-413C
NTA855-G7
HCI444FS
413
330
375
300
343kw429kva
GF-440C
NTA855-G7A
HCI444F
440
352
400
320
360kw/450kva
GF-440C1
KTA19-G2
HCI444F
440
352
400
320
336kw/420kva
GF-495C
KTA19-G3
HCI 544C
495
396
450
360
403kw/504kva
GF-550C
KTA19-G4
HCI544D
550
440
500
400
448kw/560kva
GF-578C
KTA19-G5
HCI544E
578
462
525
420
470kw/588kva
GF-649C
KTA19-G8
HCI544E
649
519
590
472
510kw/640kva
GF-633C
KTAA19-G6
HCI544E
633
506
575
460
520kw/650kva
GF-660C
KTAA19-G6A
HCI544E
660
528
600
480
540kw/675kva
GF-688C
KTAA19-G6A
HCI544F
688
550
625
500
540kw/675kva
GF-688C1
QSKTAA19-G3
HCI544F
688
550
625
500
574kw/718kva
GF-688C2
KT38-G
HCI544F
688
550
625
500
679kw/849kva
GF-798C
KT38-GA
LVI634B
798
638
725
580
640kw/800kva
GF-825C
KTA38-G2
LVI634B
825
660
750
600
664kw/830kva
GF-891C
KTA38-G2A
HCI634G
891
713
810
648
813kw/1016kva
GF-1001C
KTA38-G2A
LVI634D
1001
801
910
728
813kw/1016kva
GF-1100C
KTA38-G5
HCI634J
1100
880
1000
800
880kw/1100kva
GF-1348C
KTA50-G3
PI734A
1348
1078
1225
980
1097kw/1371kva
GF-1496C
KTA50-G8
PI734B
1496
1197
1360
1088
1200kw/1500kva
GF-1581C
KTA50-GS8
PI734B
1581
1265
1438
1150
1287kw/1609kva

More Details Information Please Contact Us

Diesel Engines for Wechai Shangchai (SDEC) Yuchai Deutz Ricardo Lovol Cumminss...and so on

Specifications

1.On Time Delivery

2.Matrial:Original spare parts

3.large stock for common parts

4.professional engine parts sales engineer to guarantee the accuracy of the parts
5.Professional Perfomance Auto & Construction Machinery parts supplier
6.Diesel Engines for Wechai Shangchai (SDEC)  Yuchai Deutz Cummins

Genset Features

B and F series product
1. Original European Technology, Independent R and D.
2. Gen-sets Power Matching Coefficient.
3. Matched with Professional High-temperature Radiator.
4. Professional Application and Integration Capabilities.
5. Option Automation, Auto-switch, Auto-parallel Connection and other Functions Freely.
6. Key Components of The Controller, Circuit Breakers, Generators for the Domestic and International Famous
7.Strong power,high reliability

Packing & Delivery
Our most professional packaging
Transport of large trucks to the seaport
And international transport cooperation
